YSI ProSwap Digital Water Quality Meter

Updated:2025-03-13

Brand:YSI
Model：ProSwap
Description: Swap one smart sensor for another with the ProSwap digital water quality meter! Featuring built-in temperature and optional depth sensors, ProSwap can transform into whatever you need: a purpose-built
Data download

Feedback
WeChat

QQ

Online Service

Product Details

ProSwap Digital Water Quality Meter Introductin：

user's manual

The highlights of ProSwap Digital Water Quality Meter include：

ProDIGITAL Platform for Enhanced Versatility

Connect any ProDIGITAL integrated probe/cable assembly to the ProSwap handheld or any ProDSS digital water quality sensor to the ProSwap cable. Sensors and cable assemblies are user-replaceable with cable lengths ranging from 1- to 100-meters.

ProDIGITAL Smart Sensors

Swap one sensor for another! The ProSwap incorporates smart sensor technology that enables sensors to be automatically recognized by the handheld. Additionally, DIGITAL sensors store calibration data, so probe assemblies can be swapped between handhelds without the need for re-calibration.

Provides Years of Sampling for All Field Conditions

The ProSwap handheld meets the demands of true field work with a rugged, waterproof case (IP-67 rated) and a military-spec (MS) cable connector. Rigorously drop tested from all angles, the handheld features a 3-year warranty, while a 2-year warranty is included with the cable assembly and any sensor variety.

Advanced Data Management

ProSwap includes KorDSS Software, a powerful data management program for easy 2-way communication between the meter and a PC. A unique data backup feature allows for the export of data to a USB flash drive (included) in csv format without having to connect to a computer.

Convenient Sampling Experience

Ergonomic handheld for a comfortable grip
Easy-to-read color display and backlit keypad
Large onboard memory with storage capacity for over 100,000 data sets
Site ID and Data ID tag capabilities for data organization
Data export directly to USB flash drive (included)
Single cable design for probe assembly lengths ranging from 1- to 100-meters
Long-life rechargeable lithium-ion battery that is user-replaceable
Simple and quick calibration procedures

Specifications：

ProSolo Specifications
Calibration:	400 detailed calibration records can be stored and are available to view, download, and print
Certifications:	CEC, CE; RoHS; IP-67; WEEE; FCC; UN Part III, Section 38.3, Test methods for lithium-ion batteries (Class 9)
Dimensions:	8.3 cm width x 21.6 cm length x 5.6 cm depth (3.27 in x 8.5 in x 2.21 in)
Display:	Color, LCD graphic display; 3.9 cm width x 6.5 cm height
Languages:	English, Spanish, German, French, Italian, Norwegian, Portuguese, Japanese, Chinese (Simplified & Traditional), Korean, Thai
Logging Capabilities:	Single point or continuous with autostable feature
Memory:	100 user-defined sites and 100 user-defined data ID tags; site pictures can be sent to the handheld via KorDSS, > 100,000 data sets
Power:	Rechargeable lithium-ion battery pack provides ~48 hours with the handheld only; battery recharge time is ~9 hours with the AC power adapter; the instrument can also be powered via AC or external power pack through the USB port
Storage Temperature	0 to 45 °C (32 to 113 °F) with battery installed; 0 to 60 °C (32 to 140 °F) without battery installed
USB	Built-in micro USB On-The-Go port for PC connection, recharging/powering the handheld and connecting directly to a USB stick<
Warranty	3-year handheld warranty
Weight	567 grams (1.25 lbs)
